Survey of Contemporary Gondola.

Set of 8 sheets from P 262 to P 269

Draughtsman: Gilberto Penzo with Antonio Rosada

Complete series of drawings 1:10 scale. Price 75 euro (plus VAT, and postage)

P 262 Cantièr and sections

P 263 Layout of the boat

P 264 Frames

P 265 Longitudinal sections and decks

P 266 Side view and bottom

P 267 Ferro di prua and lama di poppa (bow and stern ornaments)

P 268 Gondola Isometric views

P 269 P Sesti and sagome (templates)

 Full scale gondola drawings

For anyone interested in building a gondola, we suggest buying the full-scale drawings of  Full-scale half-frames (P 152) and the templates P 149, 150, P 151 Sesti e sagome

P 152 Full-scale half-frames.

New improved version in two sheets!

P 552 P 553 dim.: 170x 90 cm

Price 70 euro (plus VAT, and postage)

All frames in full size!

33 sheets, total 45 meter of paper

P 149, 150, P 151 Sesti e sagome

P 267 Ferro di prua and lama di poppa (bow and stern ornaments)  in 1:1 scale

Price 35 euro (plus VAT, and postage)

 Decorations and movable parts, for the gondola

P 154 Decorazioni e intagli per la gondola

P 152 Parecio. Parti mobili per gondola

Price 30 euro (plus VAT, and postage)
